Made in the USA with full stainless steel construction inside and out

ADA Compliant

• 32 inch height is designed to fit under ADA compliant counters

Commercially approved

• ETL-S listed to NSF-7 Standards for use in commercial establishments

Slim undercounter dimensions

• Less than 24 inches wide to fit tight spaces

Built-in capable

• Make the best use of space by installing your appliance under the counter and flush with other cabinetry

Fully finished cabinet

• Allows the unit to be used freestanding

Complete stainless steel construction

• Built with solid durability, inside and out

Automatic defrost

• Reduced maintenance with auto defrost system

Adjustable thermostat

• Dial thermostat for easy temperature management

100% CFC free

• Environmentally friendly design does not contain ozone-damaging chemicals

Dimensions
Compressor Step Height	7.0" (18 cm)
Compressor Step Width	18.63" (47 cm)
Compressor Step Depth	6.0" (15 cm)

Drawer Dimensions
Interior Height 1	6.25" (16 cm)
Interior Width 1	18.63" (47 cm)
Interior Depth 1	11.5" (29 cm)
Interior Height 2	6.25" (16 cm)
Interior Width 2	18.63" (47 cm)
Interior Depth 2	16.0" (41 cm)
Interior Height 3	6.25" (16 cm)
Interior Width 3	17.25" (44 cm)
Interior Depth 3	16.0" (41 cm)

Interior
FC - Internal Fan Internal fan for even temperature distribution throughout the unit interior	TT Thermometer ISO-17025 calibrated thermometer with glycol bottle provides temperature readout on the door; specify Farenheit or Celsius display upon order
PH - Probe Hole Factory installed probe hole for customer supplied monitoring devices	DT Digital Thermostat Install a digital thermostat with external readout for precise temperature management
Alarm Install a high/low temperature warning alarm with external temperature readout; meets most Health Dept. regulations	Latch Door latch requires manual release to open door. Ideal for yachts, RVs, coach buses, and other vehicles.
SSK Stainless steel kickplate factory installed	HUM Humidity Sensor Humidity sensor with min/max readout
HG Cord Add a hospital grade cord equipped with green dot plug with the HG suffix	DL1 Temperature Logger USB Temperature Logger records interior temperature in 15 minute intervals to a USB flash drive for analysis on a PC or Mac

Overview
Height of Cabinet	32.0" (81 cm)
Width	23.75" (60 cm)
Depth	23.5" (60 cm)
Depth with Handle	23.63" (60 cm)
Depth with door at 90°	39.25" (100 cm)
Capacity	3.1 cu.ft. (88 L)
Defrost Type	Automatic
Door	Stainless Steel
Cabinet	Stainless Steel
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Sanitation	ETL-S
Amps	1.3
Shipping Weight	140.0 lbs. (64 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years

Refrigerator Features
Thermostat Type	Dial
Fan Type	Interior and Exterior
Refrigerant Type	R134a
Refrigerant Amount	1.8oz.
High Side PSI	285.0
Low Side PSI	70.0
Level Legs Qty	4
